Home Aro Piston Pumps Aro AL0409C51FF22002 55 GAL Drum Cover Agitator w/ Lift 4 1/4 Inch 9:1 – 47093166IRI

Sale

Aro AL0409C51FF22002 55 GAL Drum Cover Agitator w/ Lift 4 1/4 Inch 9:1 – 47093166IRI

Name: Aro AL0409C51FF22002 55 GAL Drum Cover Agitator w/ Lift 4 1/4 Inch 9:1 - 47093166IRI
SKU: 47093166IRI
Availability: InStock

Original price was: £12,709.00.Current price is: £12,074.00.

£12,074.00 Ex VAT

The ARO AL0409C51FF22002 9:1 two-ball air-operated piston pump agitator system in stainless steel construction, with a double-acting design delivering fluid on every stroke. Flows up to 2.9 gpm at fluid pressures up to 1350 psig.

Product Overview

Brand

Aro

Piston Pump Type

2 ball

Product Type

System

Pump Type

Piston

System Type

Drum Cover Agitator with Lift

Part Number

47093166IRI

Pump Code

AL0409C51FF22002

Resources

Technical Specifications

Material

Stainless Steel

Porting

NPSM

Power

Air Operated

Size

1 1/4"

Ratio

9:1

Motor Diameter

4 1/4"

Fluid Inlet

1 1/4" NPSM

Air Exhaust

1 1/4" NPT(F)

Fluid Outlet

3/4" NPT(F)

Stroke

Flow Rate

10.5 LPM

Air Inlet

1/2" NPT(F)

Displacement Per Cycle

180.3 cc

Cycles Per Gallon

Flow 60 Cycles Per Min

2.9 GPM

Noise Level

89.2 dba

Fluid Pressure Range

270-1350 PSI

Air Pressure Range

30 - 150 PSI

Upper Packings

UHMW-PE

Lower Packings

UHMW-PE

Spring Type

Coil Spring, Standard Solvent Cup

Plunger Type

316 Stainless Steel

Lower Pump End

1875C51FF22
