Product Details

• Brand: Flojet
• Part Number: 122201D
• Family: LF Series

Santoprene diaphragm, Viton valves – 9.5mm (3/8″) connections

Output: – up to 3.8 litres/minute (0.8 gallons/minute). Maximum recommended total head 25m
Connections: – for 9.5mm (3/8″) bore hose
Protection Class (IP Rating): – IPX4
Fuse Size: – 5(amp)
Dimensions: – 162mm long, 100mm wide, 61mm high
Intermittent duty
Built-in thermal overload protection
Duplex diaphragm design allows extended dry running
Self-primes up to 0.7m vertical lift
PRESSURE SWITCH – cuts in at 1.7bar (25psi) – cuts out at 2.4bar (35psi)
